Klein L.¹, Dousa P², Zajicek R. ¹, Pafcuga I.¹, Tokarik M.¹

¹ Dept. of Burns Medicine,² Dept. of Orthopedics and Traumatology, 3rd Faculty of Medicine and Teaching Hospital Kralovské Vinohrady, Charles University, Prague, Czech Republic

SUMMARY. Fewer than 5 percent of all burn patients sustain other traumatic injuries before, during, or immediately after their accident. Multiple traumas associated with a burn injury create special problems during the care of the thermally injured patients. Conversely, the burn injury often complicates the diagnosis and treatment of the trauma. The combination of mechanical and burn injuries can be divided into two types a) any associated fracture located outside the burned area, or b) fractured bones within the burned area This situation represents a critical factor which must be taken into account during treatment procedures. The following options should be considered: In fractures outside the burned area, there would be no difference in standard, skeletal treatment procedures For the treatment of fractures in burned areas (mostly on the extremities). the optimal procedure is osteosynthesis within 48 hours of the burn trauma, when the burn wound is nearly sterile (without significant bacterial colonisation). We prefer two-team surgery. Firstly, a trauma surgeon performs osteosynthesis and, after that, burn surgeons treat the burns. The optimal approach in full-thickness burns would be necrectomy and autografting. This is, however, not always possible, because of the overall condition of the patient who has been continuously resuscitated during the shock period. All individual factors must be considered during the decision-making process..

Key words: thermal and mechanical trauma, associated injury, polytrauma, interdisciplinary approach, necrectomy, autotransplantation, external skeletal fixation, ostheosynthesis

INTRODUCTION

Polytrauma presents a serious medical and social problem, due to the morbidity, mortality and possible consequences in terms of a long-term disablement or permanent invalidity. There arc many various definitions of these statuses whereas all with the common basic characteristics of polytrauma: simultaneous injury to several (at least two) body systems. one of which threatens the patient's life. In some cases. polytrauma can he considered also combined or associated thermal injuries (burns) and mechanical injuries (for example fractures of the locomotor system). Combinations of these jnjuries are among the most severe ones. The overall condition of the patient depends on how severe are the particular injuries. The initial burn shock deepens and course of the acute burn treatment period worsens, complications often occur. treatment time of particular injuries extends. If there is a fracture of pelvis or femur hemorrhagic shock develops among the burn shock and the blood loss must be replaced even in the initial stages (in contrast to when there is burn injury only). A complex approach to the treatment of such patients is possible only within the scope of an interdisciplinary cooperation of particular specializations that are organized into trauma centers.

CASE REPORT

On August 1 It, 2006 at one o'clock in the morning a car accident occurred. A car crashed into a tree and caught fire. There were two passengers in the car, one died in the fire and the other, 23year-old male was rescued with severe thermal and mechanical injuries. The patient was urgently treated on the spot, including endotracheal intubation and he was transported by an air ambulance directly to the Burn Centre, where he was admitted at 02.30 AM. Later, we have found from the anamnesis that the injured man was previously healthy and he did not suffer any internal illnesses. In his early childhood he underwent a surgery for pes equinovarrus on the right and at the age of 4 he underwent bilateral prolongation of his Achilles tendons. The initial treatment revealed that the patient sustained deep burns of upper limbs, trunk, buttocks, genitals and lower limbs in the total extent of 62%r, of the total body surface area (TBSA) (Fig. 1. 2). An inhalation trauma of the airways was suspected. In the area of the right orbit there mss a hematoma and there was laceration of the patient's lower lip. Since there was disfiguration. mechanical damage to the skin on the ventrolateral side of the thigh and the whole lower extremity was positioned in an external rotation. we suspected a compound fracture in the area of right femur. Venous and arterial cannulations were completed, aggressive liquid resuscitation was continued with the use of crystalloid and colloid solutions, and frozen plasma was also given. A nasogastric tube was placed as well as insertion of a permanent Foley catheter was performed, mechanical lung ventilation was continued, and the patient was put on antibiotics Tazocin. We have completed releasing escharotomy on the right hand and forearm, suture of the lip wound and tetanus prophylaxis by application of intramuscular TAT 0.5 ml. Next, it was necessary to complete diagnostics of possible skeletal injuries and exclude possible injuries to the thoracic and abdominal cavities. The appropriate X-ray and CT scans were completed. X-ray of the right femur revealed ipsilateral fracture of the proximal end without a significant dislocation and transversal dislocated fracture of the diaphysis. Other hones were without any trauma. Head, chest and abdominal injuries were excluded; on the contrary, bronchoscopy confirmed inhalation injury of the airways. CT scan of the chest revealed a partial atelectasis of the lower lobe on the right side and subsegmental atelectasis in the left lower lobe. Consequently, the orthopedic team completes the first surgery-fixation of the right femur diaphysis fracture with the use of external fixator (ZF Mefisto) which allowed correcting the fracture into a satisfactory position (Fig. 3). Due to the overall condition of the patient and due to the type of multiple traumas we have decided to treat the pertrochanteric fracture conservatively. Next, the treatment continued on the Intensive Care Unit and was focused on mechanical ventilation, liquid resuscitation, metabolic support and surgical treatment of the burned areas. Surgical interventions then followed, usually in 48-hour-intervals, consisting of releasing incisions (Fig. 4) or necrectomies. On the upper extremities and on trunk the avulsion method was used. It concerns the so called epifascial necrectomy, where we remove skin and subcutis down to fascia (Fig. 5). The advantage of this method is significantly lesser blood loss than in the tangential (laminar) necrectomy by excisions when using Humby - or Watson -knife. Overview of the main surgical interventions is listed in Table 1.

Despite the maximum effort to be gentle during manipulation with the patient (transfers to and from the operating table, surgery on limb with the external fixator in situ, bed changes etc.) the eighth day after the osteosynthesis, there was loosening of the fixator and it was necessary to reposition and fixate the femoral bone fragments again (Fig. 6). The fracture was healing with a massive callus particularly at the medial side of femur, however. the pertrochanteric fracture gradually led to a varosity of the proximal femoral fragment. Due to angulated fragments of the diaphysis it was necessary on November 16'x,, 2006 (14 weeks after the injury) to complete an adjustment of the external fixation. We have increased rigidity of the external fixator by adding more screws. We have achieved satisfactory position; the pertrochanteric fracture was at that time already healed. During the course of the treatment the patient underwent intensive physiotherapy, initially passive and later active with the goal to prevent contractures of the small and largej oints and to limit muscle atrophy as much as possible and simultaneously maintain muscle strength. Later rebandaging including showering was performed at the standard unit. Owing to the then epidemiological situation at the workplace bacteriological assessment of wounds several times revealed a positive Methycilin-Resistant Staphylococcus aureus (MRSA). Despite that. through thorough local care and the overall treatment we managed to prevent infection in the areas of pin sites (Fig. 7-10). Since the patient had a significant psychological support from the staff, clinical psychologist, and a good family support. healing course of both types of injuries (thermal and mechanical) was positive. After five months from completion of the ostcosynthesis we have dynamized the external fixator and the patient was allowed partial weight bearing on the limb. The patient started verticalization and gait training and gradually progressed to a lull weight bearing. The patient's Overall condition at the end of the sixth month allowed for transfer to a surgical unit in the area of the patient's residence so he could continue with rehabilitation. Transplanted and harvested areas as well as both fractures continued to heal well and on March 8'°. 2007, eight months alter the injury, during an out-patieill visit it was possible to remove the external fixator (Fig. 11). The pertrochanteric femoral fracture healed in varus angulation, however, in this case we consider the position satisfactory. Fracture of diaphysis healed with a massive callus with a slight angulation. The result was shortening of the limb by 2 em which proved to be positive due to the plantar flexion in the anklejoint. The patient thrives physically and mentally and is motivated to continue with gait training and overall self care training (Pig. 12).

DISCUSSION

The combination of thermal and mechanical injuries can be divided into two types: one when the fr acture is localized elsewhere than the burned area or within the burned area. This situation represents a critical factor which must be taken into account during the choice of possible treatment procedures. Basic possibilities of therapeutic algorithms are shown in Table 2.

A majority of short bones fractures, vertebral and skull fractures are treated conservatively. which allows to fully concentrate on the treatment of burns. Complications are caused by circular burns. when the patients must be turned. Most frequently the combination of fractures and burns occur on upper or lower extremities. Fractures without dislocation of fragments can only be treated with a classical plaster cast if it is outside the burned area. Some workplaces may prefer the open-method treatment of the burn when using skeletal traction. However, the method of skeletal traction can not provide a perfect immobilization of the fractured fragments because there is a need for frequent rebandaging of the burned area. Metal material used for traction should not run through the burned area, because sooner or later it loads to an infection and loosening of the wire. The same reasons lead to certain reservations regarding the use of external fixators. Despite that. some authors recommend external fixators in open fractures or in an area with severe burns. When the skin is healed it is possible to change the external fixator to internal osteosynthesis. The most convenient treatment of fracture in the area of burn is a stable osteosynthesis that allows for a good manipulation with the extremity. However, due to severe burns in the area of thigh we have not in this case used the internal femoral fracture osteosynthesis with a reconstruction nail. which we use in cases of solely mechanical injuries. Osteosynthesis after dislocated fractures should be completed as soon as the patient's status allows. Preferably, it should be completed within 48 hours after the injury, because later than that danger of infection in the burned area increases and there is a risk of infection transmission from skin into the bone.

Opinions on surgical treatment of fracture through the burned area vary.

1. In burns of 2,,d degree where the incision runs through the burned area it is possible to sew the incision after ostcosynthesis and heat the burn as usual.
2. Experimental works on dogs in Houston cried the possibility to perform the osteosynthesis 24 hours after the necrectomy and covering of the area with autotransplants. However, the use of this method in human medicine is not further mentioned by authors.
3. In comminuted fractures it is recommended to complete the necrectomy, bloody reposition with rinsing of the fracture site with antibiotics and subsequent suture of soft tissues and closure of the defect with autotransplants or temporarily w its a biological cover (allotransplants, xenotransplants).
4. Some workplaces recommend proceeding radically with the use of early two-team surgery method. Within two days after the injury, or preferably even the same day of admission afterthe patient is prepared, a team of two surgeons erudite in the treatment of burns complete a necrectomy according to the judged depth of necrosisù and with the evaluation of transplants type. Concurrently, they harvest dermoepidermal autotransplants, which they expand by the use of meshdermatom After that the trauma surgeon completes a stable osteosynthesis Final closure of the wound is again completed by the team specialized in the treatment of burns. The subsequent treatment plan follows as usual.
5. In particularly severe comminuted fractures with derangement of the blood supply and damage to the soft tissues it is necessary to consider an amputation as a lifesaving treatment. Particularly. if the fracture is associated with a critical extent of the burn when there is danger of sepsis or in patients who would not cooperate in the treatment of combined injury due to other illnesses, in elderly patients or after a mass accident in exceptional situations. It is recommended to complete an exarticulation in the most distal joint rather than amputation through the burned area and bone due to the possibility of infection transmission.

CONCLUSION

Many traits associated with the combined thermal and mechanical injuries, particularly the treatment course, treatment method, and prognosis of the status require an individual approach to particular patients based on evaluation of factors, which describe seriousness of the burn trauma. Based on our experience we move towards more active and early surgical solution of these complicated traumatic statuses. Particularly, considering that despite not a very high absolute number of the total injuries (up to 5% of thermal and mechanical injuries) these injuries concern mainly young individuals in a productive age and who can be this way saved and returned back to active lire.

Acknowledgments

This work was ompleted within the scope of the research project supported by the grant IGA MCI NR 8853-4106.

REFERENCES

1. Alonso J., Geissler W.. I Hughes JL., External fixation of femoral fractures. Indications and limitations. Clin. Orthop. Mai. Res.,
2. Dossett AB., Hunt J1... Purdue GF., cl al. Early orthopedic intervention m burn patients with major fractures../.Trauma, 31.1991.1).888-892
3. Doiusa P., BArtonicek J., Havranek P Ipsilateralni zlomeniny proximalniho femuru Uraz. Chir., 13,2005,p 72-80. 4. Drabkova J. Polytrama v intenzivni medicine praha, grada Publishing a.s..2002, p.307
4. Charouskovà M., Men) L., Hofmann A. Nase zkusenosti s leebouzlomenin v popalenem terenu. voj Zdrav List, 52, 1993. 1).196-199.
5. Konigova R., et al. ùùkomplexni lecba popalenin Praha Grada Publising a.s. 1999,1).455.
6. Purdue GP, Hunt JL. Multiple trauma and (tie bum patient. Ain. J. Surg., 158., 1989, p. 536-539.
7. Santaneillo to AL. Luchette FA., Esposito TJ ., et al. Ten year experience of burn, trauma. and combined burn/trauma Injuries comparing outcomes TRauma 57, 2004_ p. 696-701 .
8. Scale, TM., Boswell SA Scot JD., et al, External fixation as a bridge to intramedulalry nailing for patients with multiple injuries and anti femur fractures. drainage control orthopedics. J. Trauma, Oft, 2000. p. 613,21 .
